Classic Simplicity Combined with Big Boat Performance
The 808 SL Series
Combining a proven design with state-of-the-art materials, the 808 SL furler is a user friendly, single line furling and reefing system designed for larger boats that is both reliable and virtually maintenance free. The 808 SL Furler uses state of the art materials and thoughtful design to offer a simple, reliable and maintenance-free furling system.
808 SL Series
Standard Features
The 808 SL Series furler by Hood Yacht Systems, featuring:
Download Product Sheet
Download Product Sheet
- Heavy Duty Aluminum Construction
- Lightweight Combined with Strength & Durability
- Built & Tested for Harsh Marine Environments
- One Piece Stainless Steel Tapered Sail Feeder
- Contoured, Single Piece, Electropolished Stainless Steel Drum Cover
- HYS Hybrid 1/4″ Stainless Steel Ball & 3/16″ Torsion Ball Bearings
- 316L for Rust & Corrosion Resistance
- Single Line Furling System
- 5 Year Warranty
- Simple to Install Using Standard Hand Tools
- Installation Over Existing Headstay Wire, Usually Without Modification
808 SL Series
Additional Options
808 SL Series furling system personalization options, for any application.
- Available in 5 to 7 Piece Kits and Clevis Pin Configurations to Accommodate Sailboats Up to 46 Feet
- Kit Pieces: 7 Pcs, 8 Pcs or 9 Pcs
- Wire Diameters: 5/16″ (8mm), 3/8″ (10mm), 7/16″ (11 mm)
- Clevis Pin Diameters: 1/2″ (12.7mm), 5/8″ (16mm), 3/4″ (19mm)
- Rod Size: 10, 12, 17, 22
- Max System Length: 67 feet
- Boat Size: 34-46 feet (10-14 meters)
- Hood Yacht Systems Spare Parts & Installation Accessories Readily Available
808 SL Series
Key Materials
Quality construction, built to last at sea.
- Hood Yacht Systems uses aluminum to construct our 808 SL furlers. The proprietary aluminum extrusions are precision machined, quality tested and assembled in-house.
- The 808 SL furlers are professionally assembled in-house with 316L, marine grade, stainless steel fasteners. Stainless steel is ideal for harsh marine environments due to it’s rust & corrosion resistance, strength and luster.
Hood Yacht Systems 808 SL
Furler Size Chart
| Part # | Description | # of Kit Pieces | Wire Diameter | Clevis Pin Diameter | Max System Length | Sailboat Length | PDF Drawing |
|---|---|---|---|---|---|---|---|
| H9500-8 | 808 SL Furler Kit w/ 8 Sections 54′ | 8 Pcs | 5/16″ (8 mm) 3/8″ (10 mm) 7/16″ (11 mm) | 1/2″ (12.7 mm) 5/8″ (16 mm) 3/4″ (19 mm) | 67″ | 34′-46′ (10-14m) | DOWNLOAD |
| H9500-9 | 808 SL Furler Kit w/ 9 Sections 60’6″ | 9 Pcs | 5/16″ (8 mm) 3/8″ (10 mm) 7/16″ (11 mm) | 1/2″ (12.7 mm) 5/8″ (16 mm) 3/4″ (19 mm) | 67″ | 34′-46′ (10-14m) | DOWNLOAD |
| H9500-10 | 808 SL Furler Kit w/ 10 Sections 67′ | 10 Pcs | 5/16″ (8 mm) 3/8″ (10 mm) 7/16″ (11 mm) | 1/2″ (12.7 mm) 5/8″ (16 mm) 3/4″ (19 mm) | 67″ | 34′-46′ (10-14m) | DOWNLOAD |
808 SL Series
Frequent Questions
- Hood Yacht Systems is the leading manufacturer of sailboat furling systems for enthusiasts and builders since 1947. We truly stand behind our products and pride ourselves on our outstanding customer service. All Bomar hatches are backed by our 1 year warranty against any manufacturing defects.
- Furler rod, clevis pin, and mounting hardware is included with the purchase of each furler system. Furling line, spare parts & accessories sold separately.
The best way to identify your current Hood Yacht Systems furler is to measure the outside diameter of the luff extrusions.
- 700 Series = 1-1/4″
- 800 Series = 1-3/8″
- 900 Series = 1-5/8″
Also, be sure to check the furler drum for any serial number stamps.
- Yes, Hood Yacht Systems ships products worldwide across the globe. Shipping charges will be determined and billed separately once your order is ready to ship.
- HYS offers replacement parts such as clevis pins, head stays, halyards & more for most furling systems produced after 1999. Customers may purchase these replacement items from an authorized dealer. Furler lifespan will vary case by case depending on environment, use, and individual care.
808 SL Series
Purchase Options
Purchase the 808 SL Series reefing & furling system by Hood Yacht Systems.
Request a quote
Request a quote
Hood Yacht Systems pioneered the design and manufacturing of quality, line drive furlers. We take pride in designing and manufacturing the most innovative and highest quality boating products. We stand behind every furler, hatch and portlight we make. We offer a variety of safe, secure, private and convenient purchasing options for all. Place your order online today or choose an alternative sales channel below.
